South Australia SAPN Flexible Exports and Smart Inverter Guide

Key Takeaways

• SA Power Networks offers dynamic connections enabling exports between 0kW or 1.5kW* up to 10kW per phase (subject to available network capacity.
• Constrained feeders enforce a lower fixed export between 0 and 1.5kW per phase, dependant on network area.
• Rural lines retain high export potential: the upper export limit of 10kW* is still offered to SWER customers however we anticipate.
• Under state technical mandates, sites configured to permanent zero export are exempt from Dynamic Export compliance requirements.
• Commercial energy systems with a total generating capacity greater than 30 kW are exempt from Dynamic Export compliance until 1 July 2024.

South Australia's Distributed Generation Transition

South Australia operates one of the world's highest concentrations of residential rooftop solar photovoltaic systems. In response to localized network constraints, SA Power Networks (SAPN) and the State Government developed the Flexible Exports initiative under the Smarter Homes framework.

Grid infrastructure must balance reverse power flows safely, as some parts of our electricity distribution network are reaching their maximum capacity to host solar exports. Rather than imposing permanent low static limits across entire suburbs, flexible connections dynamically adjust export limits to match real-time capacity.

Eligible customers connecting modern hardware receive variable export limits: systems can export between 0kW or 1.5kW* up to 10kW per phase (subject to available network capacity).

Regulatory Framework for Smarter Homes

The South Australian Department for Energy and Mining has legislated progressive technical requirements for all embedded generation installations:

1. Remote Communications: A standard which came into effect as of 28 September 2020 requires that the owner or operator of an electricity generating plant that will be installed on the South Australia distribution network ensure that the inverter is remote communications capable.
2. Dynamic Export Mandate: From 1 July 2023, as prescribed by the Minister for Energy and Mining, prescribed electricity generating plants must be capable of remotely updating and enacting Dynamic Export limits.
3. Hardware Capabilities: New technical standards will require that prescribed generating systems connecting to the South Australian distribution network are capable of being dynamically export limited and for export limits to be updated remotely.

Grandfathering protections safeguard existing solar owners: for existing customers there is no change to their connection agreement. New or upgrading solar customers in flexible exports eligible areas will be given a choice of 1.5kW or 0kW per phase or flexible exports. Any existing solar systems will need to be configured accordingly.

Hardware Exemptions and Commissioning Rules

Certain system configurations receive statutory relief from dynamic limitation testing:

• Zero-Export Installations: Systems where sites configured to permanent zero export are exempt from Dynamic Export compliance requirements.
• Storage Systems: Standalone AC coupled batteries, except those utilising a hybrid inverter, are exempt from dynamic export compliance requirements.
• Commercial Scale Units: New generating plants with a total generating capacity greater than 30 kW are exempt from Dynamic Export compliance until 1 July 2024.

Installers must ensure inverters are connected to reliable internet pathways and execute automated dynamic capability testing during commissioning to validate IEEE 2030.5 / CSIP-Aus network communications.
