Victron CCGX VE Power Setup Guide

Key Takeaways

• Many setup issues stem from incorrect firmware versions or missing communication adapters.
• Always check your GX device firmware version first when troubleshooting remote configuration problems.
• Be aware that your AC power supply will be interrupted when saving certain settings via Remote VEConfigure.
• Stop DIY troubleshooting and contact a technician if firmware updates consistently fail or critical system components become unresponsive.

How do I set up VE.Power systems with a Victron CCGX?

Setting up VE.Power systems with a Victron Color Control GX (CCGX) or Venus GX involves using the VE Power Setup application for firmware updates and configuration. This application allows you to manage compatible VE.Can products directly via USB or, historically, remotely through the Victron Remote Management (VRM) Portal. Note that the VRM functions within VE Power Setup are now deprecated.

Diagnosis: Troubleshooting Common Setup Issues

When experiencing problems with your Victron VE.Power setup, systematic diagnosis can help identify the root cause.

1. Check GX Device Firmware Version:

• • Symptom: Remote VE.Can firmware updates or Remote VEConfigure are not working.
  • Check: Verify the firmware version on your Color Control GX or Venus GX device.
  • Meaning: If your GX device is running firmware v2.17 or later, or if the VE.Bus firmware is version 416 or 417, Remote VEConfigure may not function. Compatibility requires VE.Bus firmware version 418 or later, and your CCGX or Venus GX should be running v2.10 or later.

2. Verify CAN-USB Adapter for Direct Connection:

• • Symptom: Unable to update VE.Can product firmware via USB.
  • Check: Ensure you have the correct CAN-USB Adapter connected between your computer and the VE.Can product.
  • Meaning: Firmware updates for VE.Can products via USB require a specific CAN-USB Adapter. Incorrect setup or a missing adapter will prevent the update process.

3. Inspect VE.Bus to VE.Can Interface Firmware:

• • Symptom: Communication issues between VE.Bus and VE.Can devices.
  • Check: Confirm the firmware version of any VE.Bus to VE.Can interface.
  • Meaning: This interface requires firmware v2.05 or higher for proper operation.

4. Observe Inverter/Charger Behavior During Remote Configuration:

• • Symptom: Inverter/charger momentarily switches off during Remote VEConfigure.
  • Check: Note if this occurs when changing specific settings, such as Assistants.
  • Meaning: Changing certain settings, like Assistants, will cause the inverter/charger to momentarily switch off and back on again. This is expected behavior and will temporarily interrupt AC power.

Common VE.Power Setup Problems and Solutions

This table outlines common issues encountered during VE.Power setup and their corresponding fixes.

Understanding Victron VE.Can and VE.Bus Compatibility

The Victron Energy system relies on communication protocols like VE.Can and VE.Bus to connect and manage various devices. The Color Control GX (CCGX) or Venus GX acts as a central communication hub, allowing you to monitor and configure products such as BlueSolar Charger 150/70 CAN-bus, BlueSolar Charger 150/85 CAN-bus, SmartSolar Chargers with VE.Can, Lynx Shunt VE.Can, Skylla-i Battery Chargers, Ion Control, and Lynx Ion.

For Remote VEConfigure to function correctly, specific firmware versions are required. Your VE.Bus devices need firmware version 418 or later, and your CCGX or Venus GX must be running v2.10 or later. Additionally, any VE.Bus to VE.Can interfaces in your system must have firmware v2.05 or higher to ensure seamless communication between different protocol devices.

Step-by-Step: Using VE Power Setup

The VE Power Setup application facilitates firmware updates and configuration for Victron devices.

1. Updating VE.Can Product Firmware via USB

This method is used for direct firmware updates of VE.Can products.

1. Download Software: Download and install VE Power Setup from the Victron Energy Software downloads page.
2. Obtain Firmware: Get the necessary firmware file from the Victron Professional portal.
3. Connect Device: Connect the VE.Can product to your computer using the CAN-USB Adapter.
4. Follow Instructions: Launch VE Power Setup and follow the on-screen instructions to complete the firmware update.

2. Remote VE.Can Firmware Update via VRM (Deprecated)

This function, while described in older documentation, is now deprecated.

1. Download Software: Download and install VE Power Setup from the Victron Energy Software downloads page.
2. Obtain Firmware: Get the necessary firmware file from the Victron Professional portal.
3. Establish Communication: Ensure two-way communication is enabled for your installation on the VRM Portal.
4. Connect to VRM: Start VE Power Setup, click "Connected to a Color Control on VRM," and enter your VRM login credentials.
5. Select Installation: Choose the required installation. Sites with Admin-rights and two-way communication enabled will be highlighted in blue.
6. Remote Scan: VE Power Setup will establish communication and perform a remote scan to find all products connected to the Color Control GX.
7. Update Firmware: Select the product and follow the prompts to update its firmware.

3. Remote VEConfigure via VRM (Deprecated)

This function, while described in older documentation, is now deprecated.

1. Download Software: Download and install VE Power Setup from the Victron Energy Software downloads page.
2. Obtain Firmware: Get the necessary firmware file from the Victron Professional portal.
3. Establish Communication: Ensure two-way communication is enabled for your installation on the VRM Portal.
4. Connect to VRM: Start VE Power Setup, click "Connected to a Color Control on VRM," and enter your VRM login credentials.
5. Select Installation: Choose the required installation. Sites with Admin-rights and two-way communication enabled will be highlighted in blue.
6. Remote Scan: VE Power Setup will establish communication and perform a remote scan to find all products connected to the Color Control GX.
7. Get Settings: Select the product you want to configure and choose "Get settings." Save the settings file with an appropriate name.
8. Modify Settings: Open the saved settings file. Depending on your system, "VE.Bus System Configurator" or "VEConfig" will open. Make the necessary changes and save the file.
9. Send Settings: Go back to VE Power Setup, choose "Send Settings," select the modified file, and wait for the process to complete.

Safety Considerations for Remote Configuration

When performing remote configurations, especially those involving inverter/chargers, it is important to be aware of potential safety implications. Changing certain settings, such as Assistants, will cause the inverter/charger to momentarily switch off and restart. During this brief period, there will be no AC power available. This means any connected loads will lose power, and if your internet connection relies on AC power, it may also be temporarily interrupted. Ensure that critical loads are not affected by a momentary power loss, or plan configurations during times when power interruption is acceptable.

Always follow general electrical safety practices. Before working on any electrical system, ensure all power sources (PV, battery, AC grid) are disconnected and locked out. Use insulated tools to prevent accidental short circuits.

When to call a technician instead

While many setup and configuration tasks can be performed by users, there are situations where professional assistance is recommended. If you encounter persistent firmware update failures, communication errors that cannot be resolved with the steps above, or if your system components become unresponsive after a configuration attempt, it is best to contact a qualified Victron Energy technician. Attempting to force firmware updates or making incorrect configuration changes can potentially damage equipment or void warranties.
