Victron Blue Smart IP65 Charger: Setup & Guide

Key Takeaways

• The Blue Smart IP65 Charger provides professional, rugged multi-stage charging for automotive, marine, and workshop battery banks.
• Handles wide AC mains fluctuations: Mains power voltage (Nominal | Min/Max) 220 - 240VAC | 180 - 265VAC and Mains power frequency (Nominal | Min/Max) 50 - 60Hz | 45 - 65Hz.
• Minimizes continuous electricity consumption: Standby power 0.5W.
• High conversion efficiency: Max efficiency 94%.
• Multi-stage intelligent charging: Charge algorithm 7-stage adaptive (4 stage for Li-ion).
• Standard lead-acid absorption/float/storage levels with temperature compensation: Normal 14.4V | 13.8V | 13.2V and High 14.7V | 13.8V | 13.2V.
• Dedicated lithium chemistry charging voltage: Li-ion 14.2V | N/A | 13.5V.
• Dynamic thermal voltage adjustments: Temperature compensation (N/A for Li-ion) -16mV/°C (-9mV/°F).
• Extreme operating thermal envelope: Operating temperature range -40 to 50°C (-40 to 122°F) with full rated output up to 30°C (86°F).
• Water-resistant, dust-tight construction: Ingress protection (IP) rating IP65.
• Built-in wireless control: Communication Bluetooth (via VictronConnect app).

Rugged Ingress Protection & Electrical Architecture

The Blue Smart IP65 Charger is engineered for harsh, wet, or dusty outdoor environments where conventional chargers would fail. Its completely sealed, fanless housing relies on natural convection cooling, eliminating moving parts and making it totally silent.

The Victron Blue Smart IP65 Charger operates on mains supply of 180 - 265 VAC (45 - 65 Hz) with 0.5W standby power, 94% efficiency, and IP65 dust and waterproof ingress protection:

• Multi-Stage Charging: 7-Stage Adaptive, 4-Stage Li-ion, Low Current Mode, Recondition Stage.
• Battery Profiles: Normal: 14.4V, High: 14.7V, Li-ion: 14.2V, -16mV/°C Comp.
• Control & Env: Bluetooth BLE, VictronConnect, -40 to +50°C, Convection.

Installation Rules & Connection Options

1. Mains Supply: Connect to standard single-phase utility or generator power across Mains power voltage (Nominal | Min/Max) 220 - 240VAC | 180 - 265VAC and Mains power frequency (Nominal | Min/Max) 50 - 60Hz | 45 - 65Hz.
2. Interchangeable DC Cables: Connect either the supplied heavy-duty battery clamps or permanent M8 eyelet connector cable directly to the battery posts.
3. Low Parasitic Drain: Maintains battery condition while consuming only Standby power 0.5W when idling on AC power.

Bluetooth Smart Telemetry & Multi-Stage Charging

The Blue Smart IP65 Charger integrates local wireless configuration with advanced battery restoration algorithms:

• VictronConnect Integration: Using **Communication Bluetooth (via VictronConnect app)**, users can track live charging current, view historical charge cycles, or select custom voltage thresholds.
• Adaptive 7-Stage Process: The Charge algorithm 7-stage adaptive (4 stage for Li-ion) algorithm cycles through Test, Bulk, Absorption, Recondition, Float, Storage, and Refresh modes.
• Standard Voltage Presets: Supports deep-cycle lead-acid at Normal 14.4V | 13.8V | 13.2V, AGM/spiral cells at High 14.7V | 13.8V | 13.2V, and LiFePO4 batteries at Li-ion 14.2V | N/A | 13.5V.
• Temperature Compensation: Applies automatic thermal derating and voltage adjustment: Temperature compensation (N/A for Li-ion) -16mV/°C (-9mV/°F).
• Thermal Capabilities: Operates across Operating temperature range -40 to 50°C (-40 to 122°F) with full rated output up to 30°C (86°F) in an Ingress protection (IP) rating IP65 enclosure with Max efficiency 94%.

Technical Specifications & Parameter Summary
