Victron EV Charging Station: Setup & Solar Integration Guide
Updated 6 September 2026 · By SolarNevs Research Desk, Dealer surveys + verified sources · 1 source · Method ↗
Key Takeaways
- The Victron EV Charging Station operates across an Input voltage range (V AC) 170 – 265VAC 50Hz delivering a Nominal power 22kW with a Rated charge current 32A / phase.
- Offers an adjustable Current output range 6 – 32A with Configurable Max. Current 6-32A Configurable Min. Current 6-32A selectable in 1A steps.
- Incorporates a universal Connector type IEC 62196 Type 2 socket compatible with modern electric vehicles.
- Equipped with integrated Wi-Fi standards 802.11 b/g/n (2.4Ghz only) for seamless Modbus TCP communication with Victron GX devices.
- Draws negligible standby power with a Self-consumption 15mA@230V.
- Features a built-in touchscreen and RGB Light Ring 55 configurable light effects available for real-time charging status feedback.
- Engineered for outdoor durability with Power terminals 6-10 mm² / AWG 10-8 Protection category IP44, an Operating temperature -25°C to +50°C, and a compact physical footprint of Weight 3 kg Dimensions (h x w x d) 377 x 307 x 148mm.
Power Connection & Electrical Protection
The Victron EV Charging Station delivers flexible AC charging for residential and commercial solar installations. It functions in both single-phase (7.3kW) and three-phase (22kW) configurations.
The Victron EV Charging Station is a three-phase AC EV charger delivering 22kW (32A / Phase) over 170-265VAC (50Hz), featuring an IEC 62196 Type 2 Socket with 6 to 32A current output:
- Communication & Setup: 2.4GHz WiFi (802.11), Bluetooth Smart, Modbus TCP to GX, 15mA @ 230V Standby.
- Display & Lighting: 4.3" Touchscreen, RGB Light Ring, 55 Light Effects, Status Feedback.
- Enclosure: IP44 Rating, 3 kg Weight, 6-10 mm2 Wire, -25 to +50°C.
When installing the electrical supply:
- Grid Input: Connect L1, L2, L3, Neutral, and Earth leads into the Power terminals 6-10 mm² / AWG 10-8. The charger accepts an Input voltage range (V AC) 170 – 265VAC 50Hz.
- Upstream Protection: Install a dedicated 40A upstream circuit breaker and an external Type A or Type B RCD per local wiring standards.
- Standby Efficiency: In idle states, the charging station maintains an ultra-low standby draw of Self-consumption 15mA@230V.
Operating Modes & GX Modbus TCP Solar Tracking
The charging station provides three distinct operating profiles configured via the touchscreen or VictronConnect app:
- Automatic Mode (Solar Excess Tracking): Communicates with the Cerbo GX or Ekrano GX over Wi-Fi standards 802.11 b/g/n (2.4Ghz only) using Modbus TCP. The GX controller measures net grid import/export via the VM-3P75CT energy meter and dynamically modulates the charger output between 6 – 32A to direct 100% of excess solar energy into the vehicle battery.
- Manual Mode: Allows the user to specify a fixed charging current from Configurable Min. Current 6-32A up to Configurable Max. Current 6-32A.
- Scheduled Mode: Automatically triggers charging during low-cost overnight off-peak tariff periods.
Status Indicators & Mechanical Specifications
The EV Charging Station combines intuitive user feedback with robust environmental engineering:
Feature | Engineering Specification | Functional Benefit |
|---|---|---|
Nominal Power | Nominal power 22kW (32A / phase) | Rapid 3-phase charging up to 22kW |
Charging Connector | Connector type IEC 62196 Type 2 | Universal compatibility with European and Asian EVs |
Visual Status | Light Ring 55 configurable light effects available | Clear color-coded feedback (Blue: standby, Green: ready, Yellow: charging) |
Operating Temperature | Operating temperature -25°C to +50°C | Reliable performance across harsh summer and winter climates |
Weather Ingress | Power terminals 6-10 mm² / AWG 10-8 Protection category IP44 | Splashproof and weather-resistant wall-mount enclosure |
Form Factor | Weight 3 kg Dimensions (h x w x d) 377 x 307 x 148mm | Compact and lightweight wallbox installation |
Add a battery at a surveyed price
Installers quote supply and fitting of the battery on this page for your existing or new system.
How this pays for the site: installers pay SolarNevs a fixed introduction fee when we pass them a genuine enquiry. They cannot pay to appear higher, and our surveyed prices are published before any introduction. You can also take our dated price tables straight to any installer.
Frequently asked questions
What is the charging capacity and input voltage range of the Victron EV Charging Station?
The EV Charging Station features an **Input voltage range (V AC) 170 – 265VAC 50Hz** with a **Rated charge current 32A / phase** and **Nominal power 22kW** in three-phase mode (August 2026).
What is the output current adjustment range for EV charging?
The unit provides an adjustable **Current output range 6 – 32A** with **Configurable Max. Current 6-32A Configurable Min. Current 6-32A** set via software (August 2026).
What vehicle connector and wireless interfaces are built into the station?
It includes a standard **Connector type IEC 62196 Type 2** socket, integrated **Wi-Fi standards 802.11 b/g/n (2.4Ghz only)**, and Bluetooth Smart with a low **Self-consumption 15mA@230V** (August 2026).
What visual lighting effects and environmental ratings apply to the charging station?
The unit features a programmable **Light Ring 55 configurable light effects available**, operates across **Operating temperature -25°C to +50°C**, and is protected by **Power terminals 6-10 mm² / AWG 10-8 Protection category IP44** (August 2026).
References
- Victron Energy: EV Charging Station Manual — accessed 31 August 2026
