Victron Orion XS 12/12-50A: Setup Guide
Updated 6 September 2026 · By SolarNevs Research Desk, Dealer surveys + verified sources · 1 source · Method ↗
Key Takeaways
- The Orion XS 12/12-50A is a 12 V to 12 V DC-DC charger featuring an input and output current setting range of 1-50 A and continuous output power of 700 W up to 40°C.
- Operates across an input voltage range of 9-17 V with an output voltage adjust range of 10-17 V (tolerance +/- 0.25%).
- Achieves peak efficiency of 98.5%, keeping thermal loss minimal in enclosed vehicle compartments.
- Low quiescent draw with no-load current consumption below 100mA and standby current below 1.5mA.
- Enclosure is IP65 rated, weighs 0.330kg, and connects using screw terminals supporting up to 4 AWG (21.2mm²) cable cross-section.
Understanding the Victron Orion XS 12/12-50A
Parameter Category | Technical Specification | Operational Rating & Value |
|---|---|---|
Continuous Output Power | Buck-boost DC-DC conversion | 700 W up to 40°C (derates 1.5% per °C above 40°C to 60°C) |
Current Setting Range | Programmable input & output limits | 1–50 A (50 A max constant short-circuit current) |
Input Voltage Range | Smart alternator / DC source window | 9–17 V DC |
Output Voltage Adjust | Auxiliary battery charge voltage | 10–17 V DC (+/- 0.25% tolerance, 10 mV rms noise) |
Peak Efficiency | Thermal dissipation rating | 98.5% maximum conversion efficiency |
Quiescent Power Draw | Standby / no-load battery drain | < 100 mA no-load / < 1.5 mA standby |
Terminals & Ingress | Physical enclosure & cabling | Screw terminals up to 4 AWG (21.2 mm²); IP65; 0.330 kg |
Communications | Telemetry & remote supervision | Bluetooth Smart (+4 dBm) & VE.Direct port (Cerbo GX / DVCC) |
The Victron Orion XS 12/12-50A is a non-isolated buck-boost DC-DC battery charger designed for dual-battery setups in vehicles, marine craft, and off-grid mobile systems. Housed in a compact IP65 enclosure measuring 137.3 x 123.1 x 40 mm and weighing 0.330kg, the unit regulates alternator power to charge auxiliary battery banks safely.
The device provides an input and output current setting range of 1-50 A with a maximum constant short-circuit current of 50 A. Under normal conditions up to 40°C, it delivers continuous output power of 700 W. At elevated temperatures from -20 to +60°C, output power derates at 1.5% per °C above 40°C.
Voltage Windows & Efficiency
The buck-boost architecture accommodates broad voltage fluctuations common with smart alternators:
- Input Voltage Range: 9-17 V.
- Output Voltage Adjust Range: 10-17 V, with an output voltage tolerance of +/- 0.25% and output voltage noise of 10mV rms.
- Efficiency: Maximum efficiency reaches 98.5%.
- Quiescent Drain: No-load current consumption is < 100mA, while standby current consumption drops to < 1.5mA when engine shutdown is detected.
Wiring & Physical Installation
DC cabling connects via heavy-duty screw terminals accommodating a maximum cable cross-section of 4 AWG (21.2mm²). The unit operates up to 2000 m altitude in environments with up to 95% non-condensing humidity.
Telemetry & Regulatory Compliance
System control and monitoring are provided via:
- Bluetooth Smart: Transmitting at +4dBm across 2402 - 2480 MHz for setup and monitoring via the VictronConnect application.
- VE.Direct Port: Wired communication for Cerbo GX integration and DVCC distributed voltage and current control.
- Compliance Standards: Certified to safety standard IEC 62477-1, Automotive Directive ECE R10-6, European Directive 2014/53/EU, and UK S.I. 2017/1206.
Add a battery at a surveyed price
Installers quote supply and fitting of the battery on this page for your existing or new system.
How this pays for the site: installers pay SolarNevs a fixed introduction fee when we pass them a genuine enquiry. They cannot pay to appear higher, and our surveyed prices are published before any introduction. You can also take our dated price tables straight to any installer.
Frequently asked questions
What is the charging current and power rating of the Victron Orion XS 12/12-50A?
The Orion XS features an input and output current setting range of **1-50 A** and delivers continuous output power of **700 W** up to **40°C** (August 2026). Maximum constant short-circuit current is **50 A** (August 2026).
What is the input and output voltage range of the Orion XS 12/12-50A?
The input voltage range is **9-17 V** and the output voltage adjust range is **10-17 V** with a maximum output voltage tolerance of **+/- 0.25%** and output noise of **10mV rms** (August 2026).
What is the conversion efficiency of the Orion XS 12/12-50A?
The Orion XS achieves a maximum efficiency of **98.5%** (August 2026).
What are the standby and no-load power consumption figures?
No-load current consumption is less than **100mA**, and standby current consumption is less than **1.5mA** (August 2026).
References
- Victron Energy Orion XS 12/12-50A Manual — accessed 31 August 2026
