Victron Freedom Won Lithium Battery Setup Guide

Key Takeaways

• A Victron GX-device running Venus OS is essential for communication and control with Freedom Won batteries.
• Always ensure both Victron devices and Freedom Won batteries have the latest firmware installed.
• Correctly configure charge and cut-out voltages according to Freedom Won specifications to protect the battery.
• Never install an inverter larger than the battery's specified maximum to prevent overload and potential damage.

How do I set up Victron inverters with Freedom Won lithium batteries?

Setting up Victron inverters and chargers with Freedom Won lithium batteries requires careful configuration to ensure optimal performance and battery longevity. A GX-device running Victron's Venus OS is required for communication between the battery and the Victron system.

Initial Setup and Configuration Steps

Follow these steps to correctly integrate your Freedom Won lithium battery with a Victron energy system.

1. Install a Victron GX-device:

• • Check: Verify that a GX-device (such as a Cerbo GX or Color Control GX) is installed and operational.
  • Meaning: This device acts as the communication hub, receiving data from the Freedom Won battery and relaying commands to the Victron inverter/charger. Without it, the system cannot properly manage the battery.

2. Update Firmware:

• • Check: Ensure all Victron devices (inverter/charger, MPPT solar charge controllers, GX-device) have the latest available firmware installed.
  • Check: For the Freedom Won LiTE battery, check if a firmware update is recommended, especially after updating Victron firmware.
  • Meaning: Up-to-date firmware ensures compatibility and access to the latest features and bug fixes. If the Freedom Won LiTE battery requires an update, contact support@freedomwon.co.za for assistance.

3. Configure Battery Settings:

• • Check: Access the Victron system's settings (typically via the GX-device or VEConfigure software).
  • Action: Set the appropriate charge and cut-out voltages based on your Freedom Won battery's system voltage.
  • • For 12V systems: Set Float and Bulk Charge Voltage to 14V. Set Cut-out Voltage to 11.5V.
    • For 24V systems: Set Float and Bulk Charge Voltage to 28V. Set Cut-out Voltage to 23V.
  • Meaning: These settings prevent overcharging or deep discharging, which are critical for the lifespan of a lithium battery. Specific 48V system settings are not detailed in the available documentation; in closed-loop communication, the battery's BMS typically dictates these.

4. Consider HV+ Systems:

• • Check: If you are installing a Freedom Won LiTE Commercial HV+ battery (e.g., 300/240 HV+), consult the battery manufacturer for specific setup instructions.
  • Meaning: High Voltage (HV) systems have unique requirements and procedures that must be followed precisely to ensure safety and correct operation.

Essential Compatibility and Safety Checks

Safety: Lithium Battery Handling

Lithium Iron Phosphate (LiFePO4) batteries are generally stable, but improper handling or setup can pose risks. Always observe the following safety guidelines:

• Inverter Sizing: Never install an inverter that exceeds the maximum power rating specified by Freedom Won for your battery model. An oversized inverter can draw too much current, leading to battery overload, especially when grid power is unavailable.
• DC Bus Pre-charging: Pay special and careful attention to the DC bus pre-charging procedure outlined in the Freedom Won documentation. Incorrect pre-charging can damage equipment.
• Physical Protection: The Freedom Won LiTE battery contains an internal protection circuit. However, avoid physical damage, extreme temperatures, or short circuits.
• Ventilation: While LiFePO4 batteries do not typically off-gas hydrogen in normal operation, ensure adequate ventilation in the battery compartment to dissipate any heat.
• Tools: When working with battery terminals, always use insulated tools to prevent accidental short circuits. Before tightening or disconnecting terminals, ensure all power sources (PV, battery, AC) are isolated. A spanner bridging terminals can short hundreds of amps, causing severe burns or equipment damage.

When to call a technician instead

While many setup steps can be performed by a competent user, certain situations require professional assistance. You should call a qualified solar technician if:

• You are installing a Freedom Won LiTE Commercial HV+ system, as these require specialized knowledge and procedures. The manufacturer explicitly states to contact them for setup instructions for HV+ models.
• You are unsure about any step in the installation or configuration process, particularly regarding wiring, high voltage connections, or complex software settings.
• The system displays persistent error codes or behaves unexpectedly after initial setup, and basic troubleshooting does not resolve the issue.
• You need to update the firmware on your Freedom Won battery and require direct support from the manufacturer (support@freedomwon.co.za).
• Your installation involves large parallel battery banks or custom configurations not explicitly covered in standard documentation.
• The installation requires opening the battery enclosure or performing any action that could void the battery's warranty.
