Sungrow Com100E Datalogger And Commercial Zero Export Guide

Key Takeaways

• The Sungrow COM100E integrates a Logger3000 datalogger for commercial solar installations.
• It enables dynamic closed-loop export power throttling by setting maximum export to 0 Watts in FoxCloud.
• Proper installation of Current Transformer (CT) clamps, with arrows pointing towards loads, is crucial for accurate zero export.
• Always ensure complete AC circuit isolation and lock-out before working on live busbars.

Understanding the Sungrow COM100E for Commercial Zero Export

The Sungrow COM100E is a smart communication box designed as a central commercial data hub. It integrates a Logger3000 datalogger and power supply within an outdoor weatherproof enclosure. This unit is engineered for residential and commercial off-grid and grid-parallel energy storage systems worldwide, supporting commercial and industrial scale applications.

Its primary function includes managing telemetry and dynamic closed-loop export power throttling. One Sungrow COM100E can manage telemetry and zero-export closed-loop control for up to 30 commercial string inverters. It is compatible with standard single-phase and three-phase electrical distribution systems globally and complies with international microgeneration safety and grid protection standards.

Configuring Dynamic Closed-Loop Export Power Throttling

The COM100E enables dynamic closed-loop export power throttling to prevent solar energy from being fed back into the grid. To achieve zero export, you must "Enable Feed-in Limitation in FoxCloud settings and configure maximum allowable export power to 0 Watts." This setting ensures that any excess generation is curtailed, keeping export at zero.

RS485 Communication and Smart Meter Integration

Effective zero export relies on robust communication between the COM100E, smart meter, and inverters. The system uses RS485 multi-inverter daisy-chain communication. To set this up, you "Connect RS485 differential communication wires A and B from the smart meter to the Meter port on the inverter." It is essential to "Maintain shielded twisted-pair cabling and verify proper RS485 communication baud rate settings" to ensure reliable data transfer and control signals.

Correct CT Clamp Installation

Accurate measurement of energy flow is critical for zero export. This is achieved using Current Transformer (CT) clamps. When installing these, you must "Install Current Transformer clamps with arrows pointing towards the household loads away from the grid incomer." Incorrect orientation will lead to inaccurate readings and potentially incorrect export limitation.

Safety Protocols for Installation

Working with electrical systems requires strict adherence to safety protocols. When installing CT clamps, especially on live busbars, you must "Ensure complete AC circuit isolation and lock-out before installing CT clamps on live busbars." This prevents electrical shock and ensures installer safety. Additionally, it is crucial to "Bond inverter chassis ground and battery metal enclosure to the main installation earthing terminal" to maintain proper protective bonding and electrical safety.

Real-Time Monitoring with iSolarCloud

The Sungrow COM100E integrates with iSolarCloud for real-time telemetry. This platform allows for comprehensive monitoring and management of the energy system. The "ESS assistant dynamically manages battery charge and discharge based on grid tariffs and load," optimising energy usage and storage according to operational parameters.

What you can check yourself, and what you cannot

You can verify the physical installation of CT clamps, ensuring their arrows point correctly towards the loads. You can also check the integrity of RS485 cabling and confirm that the FoxCloud settings for feed-in limitation are correctly configured to 0 Watts. However, any work involving opening the inverter, modifying internal wiring, or making changes to grid protection settings must be performed by an accredited installer. Modifying grid protection settings without authorisation can breach your connection agreement and compromise safety.

What the published sources do not tell you

While official documentation provides specific instructions for configuring zero export and installing the COM100E, it does not detail the exact steps within the FoxCloud interface for enabling feed-in limitation. The precise menu navigation or software version dependencies for these settings are not provided. Similarly, specific RS485 baud rate values are mentioned as needing verification but are not explicitly stated. These details typically reside in the full product manual or software interface documentation, which can vary by firmware version.
